MEMS gyro for positioning and autonomous navigation
of aerospace systems

Closed-loop digital MEMS gyroscope fitted for UAV and VTOL

Key gyro performances

  • ± 300 °/s range, single-axis gyroscope
  • Bias instability: 0.4 °/h (typ), 2°/h (max)
  • Angular Random Walk: 0.07 °/√hr
  • Vibration rejection: 0.5 °/h/g²
  • Residual scale factor over temperature range: 160 ppm
  • Latency: ≤ 1 ms
  • Mean Time Between Failure (MTBF): > 1 000 000 hours
  • Available in 3 resonent frequency configurations to minimize mechanical cross-coupling in multi-axis applications

Key features

  • 24-bit digital SPI interface
  • Initial and continuous self-test
  • Factory-calibrated over temperature
  • Hermetic ceramic SMD package
  • Non classified under dual-use export control
  • REACH and RoHS compliant

Key applications

  • IMU & INS for UAV and drones
  • AHRS (Attitude & Heading Reference System) for eVTOL aicraft
  • INS for GNSS-assisted positioning and navigation of ground vehicles & trains
  • IMU for precision robotics and remotely operated vehicles
  • Stabilization systems
High performance inertial sensors VTOL navigation

GYPRO®4300: High performance ± 300 °/s MEMS gyroscope with digital interface

GYPRO4300 HIGH PERFORMANCE DIGITAL MEMS GYRO

High bias stability for precision positioning and navigation in dynamic aerospace applications

GYPRO®4300 is a high-performance, closed-loop digital MEMS gyroscope with ± 300 °/s input range and 200 Hz that offers a cost-effective alternative to entry-level Fiber Optic Gyroscopes (FOG) and Dynamically Tuned Gyroscopes (DTG) at a fraction of their size, weight, and power consumption.

With an excellent bias instability of 0.4°/h as typical value (2°/h maximum) and an Angular Random Walk (ARW) of 0.07 °/√h, GYPRO®4300 brings to the market a miniature, digital and low-SWaP (Size, Weight and Power) high performance MEMS gyro that paves the way to a new generation of precise positioning, navigation, and stabilization functions in dynamic applications such as VTOL (Vertical Take-Off and Landing) aircraft and UAV (Unmanned Aerial Vehicles).

Get the datasheet
