MEMS gyro for motion control and positioning

High performance ± 300 °/s MEMS gyroscope with digital interface

High bias stability for precision navigation and positioning in dynamic applications

GYPRO®4300 is a high-performance, closed-loop digital MEMS gyroscope with ± 300 °/s input range that offers a cost-effective alternative to entry-level Fiber Optic Gyroscopes (FOG) and Dynamically Tuned Gyroscopes (DTG) at a fraction of their size, weight, and power consumption.

With an excellent bias instability of 0.4°/h as typical value (2°/h maximum) and an Angular Random Walk (ARW) of 0.07 °/√h, GYPRO®4300 brings to the market a miniature, digital and low-SWaP (Size, Weight and Power) high performance MEMS gyro that paves the way to GNSS and sensor-fusion precise positioning, navigation, stabilization functions in dynamic applications such as railway, land vehicles, VTOL (Vertical Take-Off and Landing) aircraft and UAV (Unmanned Aerial Vehicles), and marine systems.

The hermetic ceramic SMD package combined with a 24 bits SPI interface eases the integration of GYPRO®4300 and reduces the BOM. The built-in self-test ensures initial verification of the sensor’s integrity and continuous in-operation functionality test.

Let's talk about your project!

Name

Surname

Tel

Company

Country

Message

I accept the Terms of Use, the Privacy Policy, and the Cookie Policy and give consent to Tronics Microsystems, a TDK Group Company to process my personal data. My consent can be withdrawn at any time with future effect.

MEMS gyroscope for precision sensor-fusion and GPS-assisted navigation

Key performances

± 300 °/s range, single-axis gyroscope
Bias instability: 0.4 °/h (typ), 2°/h (max)
Angular Random Walk: 0.07 °/√hr
Vibration rejection: 0.5 °/h/g²
Residual scale factor over temperature range: 160 ppm
Latency: ≤ 1 ms
Mean Time Between Failure (MTBF): > 1 000 000 hours
Available in 3 resonant frequency configurations to minimize mechanical cross-coupling in multi-axis applications

Key features

24-bit digital SPI interface
Initial and continuous self-test
Factory-calibrated over temperature
Hermetic ceramic SMD package
Non classified under dual-use export control
REACH and RoHS compliant

Key applications

INS for GNSS-assisted positioning and navigation of ground vehicles & trains
AHRS (Attitude & Heading Reference System)
MRU (Motion Reference Units)
IMU for precision robotics and remotely operated vehicles
Stabilization systems
Test instrumentation
